1TB PCIe NVMe Gen4 TLC 4D NAND HMB-SLC Cache M.2 (2242) Solid State Drive
$185.00
- Geniune Lenovo Part
| Condition | New |
|---|---|
| Warranty | 1 Year |
| Availability | In Stock |
| Manufacturer | SK hynix Inc. |
|---|---|
| UPC Code | Does Not Apply |
Details
Product Specs
| Capacity | 1 TB |
|---|---|
| Cache Buffer | 64MB Host-Memory-Buffer (HMB) Pseudo-pSLC Cache |
| Flash Type | TLC 4D NAND Flash Memory (Tri-Level Cell) |
| Form Factor | M.2 2242-S3-M (M Key Single Sided) |
| Interface Speed | PCIe Express NVMe Generation 4.0 x4, NVMe v1.4 (4-Lanes) |
| Interface Connector | M.2 NGFF (M Key) |
| Sequential Read | up to 6,500 MB/sec (128KB Crystal Mark Disk) |
| Sequential Write | up to 5,500 MB/sec (128KB Crystal Mark Disk) |
| Random Read | up to 950,000K IOPS (QD32) |
| Random Write | up to 1,200,000K IOPS (QD32) |
| SSD Endurance | 400 TBW (Total Bytes Written) |
| Life Expectancy | 1.5 Million Hours MTBF (Mean Time Before Failures) |
| Shock Resistance | 1,500G, duration: 0.5ms, 3 axis |
| Ecc Recovery | Low-Density Parity Check (LDPC) Error Correction Technology |
| Encryption | Yes - TCG Pyrite 2.01; ATA Security Passthrough over NVMe |
| Rohs Compliant | Yes |
| Dimensions | (L x W x H) 42.15mm x 22.15mm x 2.38mm |
| Notes | Bare Drive (No Bracket, Connector or Screws) |
| Classification | Pro Level |
Key Features
- Fast Start-Up, Loading and File Transfers
- Up to 10x Faster than a Traditional HDD
- Shock and Vibration Resistant
- Reliable Operation with no Moving Parts
- Consumes Less Power for Longer Battery Life
- Silent Operation & Generates Less Heat
- Host Memory Buffer (HMB) SLC Caching
- Active Garbage Collection
- SRM ECC & CRC32 Data Path Protection
- SMBus Thermal Management Technology
- Advanced Power Management Technology
- Bad Block Management Technology
- Dynamic and Static Wear Leveling Technology
- Embedded Programable RAID Engine Technology
- Dynamic Write Acceleration Technology
- NANDXtend 4K Codeword LDPC Error Correction Technology
- Trim Support Technology
- Enhanced Defect and Error Management Technology
- Built for Laptops, Desktops, Workstations and All-in-One PCs
